High-precision Servo Rotary Platform

This high-precision servo rotary platform is specifically engineered for laboratory and industrial applications requiring reliable, heavy-duty, and low-runout rotary motion. Featuring a robust 2000 mm diameter working surface, the platform is capable of supporting loads up to 5 tons while maintaining exceptional flatness and rotational accuracy.
Constructed from HT250 cast iron and stress-relieved steel structures, the platform ensures long-term mechanical stability and vibration resistance. It is pneumatically clamped from four directions to prevent micro-movements during operation, making it ideal for precision positioning and testing applications.

Contact Us Now
Specification

Model

High-precision Servo Rotary Platform

Loading Capacity

5000kg

Platform Diameter

2000mm

Max. Rotation Speed

2.7 r/min

Rotational Accuracy

Axial runout ≤ 0.05 mm

Radial runout ≤ 0.1 mm

Power

2.5kW

Self Height

550mm

Power Supply

3-phase/380V

Motor Type

Servo Motor

Braking System

Pneumatic clamping mechanism

Note: The above parameters are for reference only, all products can be customized

Features

  1. High Precision and Stability：Engineered for demanding laboratory and industrial applications requiring consistent and accurate rotary motion with minimal runout.

  2. Robust Construction：Built with high-grade cast iron and stress-relieved steel, ensuring structural stability, vibration resistance, and long-term durability.

  3. Reliable Pneumatic Braking System：Pneumatic clamping from four directions ensures zero micro-movement during operation, enhancing safety and precision.

  4. Customizable Surface Finishing：Treated with a durable epoxy zinc-rich primer and polyurethane topcoat, with color customizable to client requirements for corrosion resistance and aesthetic integration.

  5. Flexible System Integration：Designed without a built-in electrical control system, allowing seamless integration into existing automation or control setups as needed.
